Advantages of the Grinder Hog

The Grinder Hog features a grinder head on each side of the truck that is capable of extending outward up to 36” (91.4 cm) from the chassis. The grinder head supports PCD teeth available in full round, double round, and full flat for different profile adjustments. The Grinder Hog is available in 2, 3, and 4-Head configurations

With our Low-Speed Control, the Grinder Hog can grind at speeds up to 6 MPH (9.65 KPH) without having to check between the crosshairs and the speedometer, greatly reducing the margin for error.

The Grinder Hog's 3 and 4-Head models come with a standard 1,000 gal (3,785 liters) water tank that can be filled with fresh, potable water for dust control while grinding, keeping the machine within OSHA guidelines.

With the Grinder Hog's Master/Follower function, one operator can run all heads and maintain exact lane width.

Sonic Vibration Technology: Over 500 Sq Feet of Filtration with auto-reverse air pulsing (Short pulse provides cleaning your filters while grinding) / Long Pulse w/Sonic vibration helps to restore air flow). Positive Displacement Blowers provide up to 6,600 CFM at 15" Hg

The Grinder Hog comes with a skip line control system for on-the-fly adjustment of grinding patterns. The Grinder Hog comes standard with 1 grinder on each side of the truck; however, there is an option to add a second grinder on each side for a total of four grinders.

The simultaneous vacuum recovery system of the Grinder Hog utilizes one, two or three 8” 2,200 cfm Roots Blowers (for 2-Head, 3-Head, and 4-Head models, respectively), double filtration, and an ultra-quiet Hog Silencer to collect debris at the same time as grinding. The debris is then stored in a 5 cubic yard debris tank (2-Head model) or a 6 cubic yard debris tank (3 & 4-Head models) that can be tilted at a minimum of 47 degrees for easy debris dumping.

The Grinder Hog uses Computer-Controlled Profiling (CCP) for grinding, grooving, sinusoidal rumble strips and plunge cuts.

The Grinder Hog uses smart cylinders which allow for computer-controlled precision depth control.

Videos of the Grinder Hog Applications

With heads on both sides of the truck, center line and shoulder work can be performed simultaneously. In addition, road reflectors can be removed and vacuumed so there's no need to remove them prior to the job.

Technical Specs

Grinder Heads13" (33 cm) Cut Width / 20" (51 cm) Cut Diameter
Vacuum Recovery (2 Heads)1x 2,200 cfm 8" blowers
Vacuum Recovery (3 Heads)2x 2,200 cfm 8" blowers
Vacuum Recovery (4 Heads)3x 2,200 cfm 8" blowers
Water Tank (3 and 4 Head Models) 1,000 gal (3,785 liters) (No tank on 2-Head model)
Debris Tank5 Cubic Yards (2-Head Model), 6 Cubic Yards (3 & 4-Head Models)
Low-Speed ControlUp to 6 MPH (9.65 KPM)

Request the Grinder Hog Specifications Sheet

Get the Grinder Hog specifications sheet that you can print and save to your computer for review at any time. A great tool for model comparisons and for comparing the Grinder Hog to other manufacturers equipment. Specifications sheet contains:

  • Complete Model Specifications
  • List of Model Options
  • List of Model Applications
Grinder Hog Spec Sheet
